Custom High‑Precision Positioning and Inspection Fixture
Custom‑designed fixturCustom‑designed fixture for fast, repeatable positioning and dimensional inspection of your specific parts.e for fast, repeatable positioning and dimensional inspection of your specific parts.
Description
This fixture is engineered to fit your part geometry (based on 3D models or physical samples) and is constructed from SKD11 tool steel or 7075 aluminum alloy, with precision‑ground working surfaces. It achieves positioning accuracy of ±0.01mm and incorporates quick‑clamping mechanisms, standard inspection pins (go/no‑go gauges), and stop blocks to enable rapid on‑line inspection and reduce human error.
We provide a complete service from design, machining, assembly, to on‑site debugging. Optional wear‑resistant coatings or anti‑rust treatments are available depending on your usage frequency and working environment. Every fixture is tested with actual parts before delivery to guarantee performance.
